Air Impact Wrench
NC-398 Contact Us
+ Compared with geared angle impact, the gearless angle impact reduces vibration , increase torque output.
+ Easy access in confined work spaces, short and stubby with 88 mm x 245 mm.
+ Low reaction force.
+ One handed Forward – Reverse operation 3 positions in forward and 1 in reverse.
+ Jumbo Hammer Type
Read More +
Download
SPECIFICATIONS
Torque Range
50-200 (FT-LB) / 68-271 (Nm)
Max Torque
300 (FT-LB) / 407 (Nm)
No Load Speed
6500 (R.P.M)
Avg. Air Consumption
4.2 (CFM) / 119 (L/min)
Air Pressure
90 (PSI) / 6.3 (bar)
Overall Length
9-3/4" / 247 (mm)
Net Weight
1.37
Net Weight
3.0
Air Hose
3/8"
Sound Pressure
85.0 (dBA)
Vibration Level
2.0 (m/s²)
Air inlet
1/4"
Bolt Capacity (Screw)
9/16" / 14 (mm)
Bolt Capacity (Nut)
22 (mm)
