Air Impact Wrench
NC-3810 Contact Us
+ Butterfly type forward/reverse trigger.
+ 180 degree turnaround air inlet.
+ Three speed adjusting switch.
+ Twin Dog Type.
Read More +
Download
SPECIFICATIONS
Torque Range
5-50 (FT-LB) / 7-67 (Nm)
Max Torque
75 (FT-LB) / 101 (Nm)
No Load Speed
11000 (R.P.M)
Avg. Air Consumption
2.3 (CFM) / 65 (L/min)
Air Pressure
90 (PSI) / 6.3 (bar)
Overall Length
5-15/32" / 139 (mm)
Net Weight
0.50
Net Weight
1.1
Air Hose
3/8"
Sound Pressure
91.0 (dBA)
Vibration Level
3.6 (m/s²)
Air inlet
1/4"
Bolt Capacity (Screw)
3/8" / 10 (mm)
Bolt Capacity (Nut)
17 (mm)
